Motion Control – Linear Slides and Components

Vaughan, Ontario, Canada — Motion Control Components — Bishop-Wisecarver invented the DualVee® guide wheel over 50 years ago in four sizes of carbon steel as a component-based problem solver for harsh, debris-laden environments. It’s 2019. They now offer product options that include UtiliTrak® linear guides, LoPro® linear actuators to complete actuated system solutions.

LoPro® Linear Actuators excel in high speed, long length and dirty environments. UtiliTrak® is constructed with DualVee Motion Technology® in vee and vee/crown designs, and using MadeWell® Crown Rollers, and are perfect for commercial applications in need of a compact, easy-to-install, and low maintenance solution.

Both LoPro® and UtiliTrak® are available as part of the Bishop-Wisecarver QuickShip Program (ships from the facility within 3 business days).

Learn how LoPro® and UtiliTrak® can be the ideal linear guide solutions for your packaging application.

CLICK HERE to view Information on the LoPro® Linear Actuators from Bishop-Wisecarver

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Blog: https://electromate.wordpress.com/

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

To see all of Electromate’s Products and Application Stories featured on MotionShop.com, enter electromate in the Google custom search box (upper left, above)

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com

See this and other Motion Control Components from Electromate featured on:

http://MotionShop.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

http://MotionControlMarketing.com

http://Gotcha-Stick.com

Motion Control – XY High Resolution Stage

Van Nuys, CA – — Motion Control – OES (Optimal-Engineering Systems, Inc.) has added a new, larger, high load, precision stage to it’s extensive line of precision XY stages. The AU200-170×170 stage is a low profile stage measuring just 108 mm (2.252 in) high with a compact footprint (including the motors) of 458.5 mm x 458.5 mm (18.032 in.) The linear travel of the X and Y axes is 170mm x 170mm (6.692 in.), and the resolution of each axis is 20 microns (non-micro-step) or 1 micron (20 micro-steps per step motor driver in use), repeatability is 2 microns, and the positional accuracy is 3 microns. The 4 mm per-turn lead screws have just 2 microns of backlash and the stages have preloaded V-groove and crossed roller bearings contributing to the high precision and stiffness of the AU200-170×170 Stage. Designed for applications such as: alignment, assembly, laser drilling, machining, medical, industrial, semiconductor handling, testing, scanning, and optical applications, this compact, low profile black anodized aluminum XY stage is easy to integrate into new or existing systems.

The XY stage’s table measures 300 mm x 300 mm (11.8 in x 11.8 in.) and features a precision pattern of drilled and threaded mounting holes to facilitate the addition of tooling or fixtures. Additionally a table with a large open aperture is also available.

The standard two-phase (1.8o) stepper motors have knobs for manual adjustments of each axis of the stage, however, the knobs can be replaced with incremental encoders for position verification or closed loop operation. As an option, servo motors and compatible motion controllers are also available from OES, or the AU200-170×170 Stage can be ordered as a complete plug-and-play motion control system.

About OES – Optimal Engineering Systems, Inc. (OES) is a manufacturer of motion control products including: Stepper motor controllers and drivers, solenoid electronics, and positioning stages and slides. Applications include: Animation, automated assembly systems, automation, CNC machines, flight simulation, inspection systems, linear and rotary stages, machine tools, medical devices, motion control camera boom systems, optical comparators, CMMs, pan-tilt gimbals, PCB assembly & inspection, pick-and-place, positioning stages, robotics, scanners, security cameras, telescope drive mechanisms, time-lapse photography and winders.

Some of the industries OES serves are: Aerospace, Astronomy, Chemical, Communications, Educational Institutes, University, Colleges, Government Agencies, National Labs, Manufacturing, Medical, Metrology, Military, Motion Control, Museum, News Agencies, Semiconductor and Test Equipment. Optimal Engineering Systems, Inc’s. competitive advantage is its state-of-the-art in-house manufacturing facility in North America enabling OES to supply clients with custom designed orders or high volume just-in-time deliveries globally.

For additional information, contact sales team at: OES, 6901 Woodley Ave.; Van Nuys, CA 91406; Telephone: 888-777-1826 or +1 818-222-9200, FAX +1 818-436-0446 or E-Mail: sales@oesincorp.com or visit the website at http://www.oesincorp.com

For other Motion Control Components, Applications, and Technology from OES (Optimal Engineering Systems) go to: http://MotionControlWeb.com

Motion Control- ETX Linear Bearing/Pillow Blocks

E. Longmeadow, MA Motion — Control Components – Linear Motion – LM76 now offers one piece ETX Linear Bearing/Pillow Blocks that will not degrade in a radioactive environment! Machined from a solid block of self lubricating ETX, linear bearing-blocks have high strength, excellent wear resistance, low coefficient of friction, and excellent dimensional stability at higher temperatures as there is no other materials such as PTFE seals or lubricants these bearing-blocks are maintenance free.

Custom designed for use in a nuclear power plant these linear bearing/pillow blocks travel on ceramic coated shafting (also supplied by LM76) completely submerged in radioactive water. Designed with a slight interference fit between bearing ID and shaft, contaminates are scraped from the shaft’s surface. The low frictional characteristics of ETX have little impact on drive force. They are now available in Inch and Metric sizes.

ETX bearing-blocks are also FDA/USDA/3-A Dairy compliant and are also are ideal for: Pharmaceutical, medical, food, and dairy processing applications.

EXT features a high continuous service temperatures up to 210°F (100°C) and offers good chemical and abrasion resistance, low moisture absorption, and resistance to staining. These ETX linear bearing-blocks with the slight interference fit keeps the bearing free from debris and bacterial contamination, are not affected by biological fluids, mild acids, can be washed down with cleaning agents, and steam cleaned.

Don’t need solid EXT bearing-blocks consider the FDA/USDA/3-A Dairy compliant electroless nickel coated or stainless steel pillow blocks with PTFE linear bearings and Snap-in EXT Scraper Seals which are available for closed linear bearings, and closed pillow and flange blocks.

To follow the NEW Series from LM76, THE ENGINEERING EDGE! and learn about interesting Outside-of-the-Box solutions developed by LM76 to solve some interesting linear motion problems! CLICK HERE

About LM76

Founded in 1976, LM76 has been a leading designer/manufacturer of linear bearings, slides and linear motion systems. LM76 is renowned for its industry leading Minuteman PTFE Composite linear bearings. LM76 is a leading supplier of precision linear shafting: RC60, 300 Series Stainless Steel, and ceramic-coated aluminum shafting. LM76 also offers several FDA/USDA compliant linear bearings and slides for the food processing, pharmaceutical, medical, and packaging industries.

For additional information contact Mike Quinn at: LM76, 140 Industrial Dr., E. Longmeadow, MA 01028; Telephone: 413-525-4166, Fax: 413-525-3735 or E-Mail: mquinn@lm76.com or visit the website at http://www.lm76.com

See this and other Motion Control Components from LM76 featured on:

The LM76 Blog

LM76 Catalogs

http://MotionShop.com.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

Motion Control – Application

While robotic assistance systems are available for most types of surgery today, eye surgery used to be an exception. A Dutch company has changed that. A world first in eye surgery.

© 2016 Preceyes

Fall River, MA — Motion Control Components Application – Worldwide, about 50 to 70 million people are suffering from visual impairment due to disorders of the retina. Adequate treatment is still impossible in many cases.

Eye operations are always a big challenge for a surgeon, and steady hands are a key requirement. Surgeries like those for treating a detached retina require extreme precision. And when it comes to precision, human hands can’t hold a candle to robotic systems.

Motion Control – Miniature Integrated Motor

Vaughan, Ontario, Canada — Motion Control Components — Maxon have released the new EC-i30 20W Brushless Servo Motor with Integrated Electronics. With an integrated 4 Quadrant speed controller, this latest addition to the EC-i portfolio is available as a 5-wire version.

Both enable and direction versions of the motor are offered.

Motion Control – Application – Underwater Robot
Motion Control Application – Specially designed robotic crawler navigates around the underwater portion of a ship to remove the biofilm layers that accumulate there. As a battery operated, autonomous vehicle, component selection made up a highly critical part of the design and manufacture.

The HullBUG provides grooming of the biofilm that collects on the underwater portion of ships.

The HullBUG provides grooming of the biofilm that collects on the underwater portion of ships. © 2011 SeaRobotics

Fall River, MA — Motion Control Components Application – Toxic paint is used on the bottoms of large ships to prevent fouling, which is when a biofilm layer develops, decreasing the ship’s efficiency in moving through the water.

Motion Control – Vacuum Compatible Voice Coil Motor

Van Nuys, CA – Motion Control Components – Moticont has added a vacuum compatible voice coil motor to its line of linear DC motors. This vacuum compatible, clean, brushless, quiet, efficient, low inertia, high acceleration, high speed linear DC voice coil motor has zero cogging and features high accuracy, and high repeatability when operated in a closed loop as a DC servo motor. The new LVCM-038-038-01-VAC Vacuum Compatible Linear Voice Coil Motor has a stroke length of 0.75 in. (19.1 mm) with a high force-to-size ratio of 3.0 lb (13.4 N) and a peak force of 9.5 lbs. (42.5 N) at a 10% duty cycle.

The motor features two 8-32 UNC-2B threaded mounting holes in the housing and two 8-32-UNC-2B threaded mounting holes on the coil end for easy integration into new and existing applications. Also called a moving coil motor, the compact 1.50 in. (31.8 mm) diameter LVCM-038-038-01-VAC Vacuum Compatible Linear Voice Coil Motor is ideal for: Medical devices, scanners and laser beam steering and filtering, work holding and clamping, testing, wafer handling, optical focusing, in vacuum applications.

Complete plug-and-play systems including an encoder and servo controller are available. Is there a need for a smaller or larger diameter motor, one with longer travel, or more force? There are more than 12 in the expanding series of Moticont’s LVCM linear motors based on diameter of the motor, and over 50 models based on length of stroke and/or force to select from. To find the right motor for your application go to http://moticont.com/voice-coil-motor.htm

About Moticont – Moticont is a manufacturer of motion control products. Their product line includes voice coil motors, three phase brushless motors and positioning stages and slides.

Moticont is committed to exceeding Our customers’ quality expectations and industry standards throughout the design, manufacturing, service and technical support phases. Our modern manufacturing facility, highly controlled processes, committed staff, and extensive testing complement our product design strengths. This enables us to supply our clients with specialized small orders to high volume just-in-time deliveries.

We offer an extensive line of standard products ready to be shipped immediately from stock, and when standard products are not quite right for an application, highly trained design engineers are always available to develop custom motion control products to fit the specific needs or our customers.

For additional information contact Sales Team at Moticont, 6901 Woodley Ave, Van Nuys, CA 91406; Toll Free: +1 (888) 785-1804, Tel: +1 (818) 785-1800, moticont@moticont.comor visit the website at http://www.moticont.com

We are excited to invite you to the Electromate Automation Fair on November 6, 2019. The event will take place at the Delta Hotels Burnaby Conference Centre in Burnaby, British Columbia. The Automation Fair is a great opportunity to explore new technologies and see what’s changing in the world of Automation and Motion Control. Don’t miss this opportunity to meet some of leading manufacturers in the Automation Industry, as well as like-minded industry professionals.

Manufacturers in Attendance Include:

Advanced Motion Controls

Applied Motion Products

Exor Electronic

Galil Motion Control

Gam Gear

Kollmorgen

Macron Dynamics

Maxon Motor

Posital Fraba

Harmonic Drive

Tolomatic

Who would benefit from this Seminar:

OEM’s, Custom Machine Builders and End Users in the following industries: Medical, Pharmaceutical, Life Science, Subsea, Robotics, Industrial Automation, Food & Beverage, Forestry, Packaging, Film & Entertainment, Scientific, and Communication Industries.

Topics Covered Include:

Industrial Automation

Motion Control

Robotics

Machine Control

Motor Control

The Agenda Includes:

Lunch will be served as well as snacks/drinks throughout the day. A host bar (beer & wine only) will be open from 1:00pm to 7:00pm.

Cost to attend the Automation Fair is FREE, however preregistration is required. Click HERE to register.

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Blog: https://electromate.wordpress.com/

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com

Motion Control Integrated Step Motors

Vaughan, Ontario, Canada — Motion Control Components — JVL Industri Elektronik A/S, one of the world leaders in the field of integrated servo – and stepper motors introduces a new compact and slim stepper motor. The new ServoStep integrated stepper motor series MIS171 to MIS176 have a NEMA 17 42×42 mm flange and include controller with 6 different industrial Ethernet protocols, absolute multiturn encoder, closed loop and M12 connectors. This new motor family is based on the latest microprocessor and cooling technology and an advancement compared to previous designs.

All the necessary electronics in a stepper system are integrated in the motor itself and are similar to the concept used by other JVL motors, making it very easy to use in all kind of motion control stepper or servomotor applications. The motor contains everything needed to solve a modern control task, either as a stand-alone with own easy programmable motion controller or controlled from an external PLC or PC. 8 I/O points can be individually configured as digital input, digital output or analogue input. Modbus RTU or CANopen provide easy connections to a PLC or HMI. An ActiveX/OCX driver is available to make simple interface to LabView, Excel, VB or other Windows-programs. Up to 254 axis can be connected on the same RS485 bus.

Key features:

• Industrial Ethernet. 6 Protocols
• Very high motor power and torque
• Closed-loop operation with current control
• Absolute multiturn encoder
• Safe Torque Off (STO) input
• High resolution 409600 cnt/rev.
• Speed 0-3000 in 0.01RPM steps
• Wide supply range 7-72 VDC
• Protection class up to IP67
• M12 or M23 connectors

Motion Control Industrial Ethernet:

Profinet, EtherCAT, Powerlink, EtherNet/IP, Modbus TCP or SERCOS III are available and for EtherCAT and SERCOS III synchronization and drive profiles are available. MACtalk can use Ethernet for commissioning the motor so no need for RS232/RS485 converter or additional cables. The motor has the ability to be upgraded with other protocols or newer versions of the same protocol at any time Because of the upgradeability, the JVL Industrial Ethernet module is also ‘future proof' as newer versions of the protocols will always fit into the design. The motor is equipped with two Ethernet connectors and a built-in switch, enabling line topology without any extra expensive hardware. Several LEDs, enabling technicians and operators to get a quick status overview.

Motion Control Motor range:

• MIS171 with 0,15 Nm, length 70,5 mm. 5mm shaft
• MIS173 with 0,26 Nm, length 83,5 mm. 5 or 6,35mm shaft
• MIS176 with 0,80 Nm, length 104,3 mm. 8 mm shaft

The motors can be operated as stand-alone units or controlled from a PLC or PC. The 8 I/Os can be individually configured as digital input, digital output or analog input. As standard, it is possible to communicate with holistic systems via for example Modbus RTU or CANopen. The MAC motor standard protocol that is also supported makes it possible to connect up to 254 other JVL integrated motors. The MIS17 series allows connectivity to all industrial Ethernet interfaces such as Profinet, EtherCAT, Powerlink, EtherNet/IP, Modbus TCP and SERCOS III.

Motion Control Interface:

• Industrial Ethernets Profinet, EtherCAT, Powerlink, EtherNet/IP, Modbus TCP and SERCOS III
• CANopen DSP402 and DS301
• Pulse/Direction mode for electronic gear
• High speed position capture
• ActiveX/OCX driver as well as JVL MacTalk Protocol
• Strong graphic programming with + – * / calculations and advanced features
• SSI interface for external linear or rotary absolute encoders
• External encoder for dual closed-loop.
• RS485 up to 921 kbit and Modbus RTU
• RS422 and RS485 for encoder I/O and connection to external HMI, PLC or encoder
• Point-to-point or multi-axis operation with up to 254 JVL motors on the same RS485 bus
• Wireless Industrial Ethernet through Bluetooth or WLAN

Motion Control Motor specification:

• Built-in PLC with 8 DIO, 24V or 0-5V (12bit) analog input with advanced filtering
• Speed-precision 0.01 RPM. Acceleration-precision 1 RPM / sec.
• Absolute multi-turn encoder
• Built-in encoder for closed loop and stall detection and control
• Wide supply range of 7-72 VDC provides high torque at high speeds
• Dual supply maintain position values etc. in emergency situations
• Motor current 0-4 Amp RMS and 5,6 Amp peak
• Closed-Loop operation
• Double shaft and brake option
• All connections with M12 connectors in IP67
• Top or rear-end mounted M12 or M23 hybrid connector

For further information on the JVL ServoStep Series Motors, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Google+: https://plus.google.com/104057418684128701566

Blog: https://electromate.wordpress.com/

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

To see all of Electromate’s Products and Application Stories featured on MotionShop.com, enter electromate in the Google custom search box (upper left, above)

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com

Motion Control Application – Implantable medication delivery systems can have a decisive influence on the quality of life of the patients. In many cases, such delivery systems are vital for the survival of the patients – the systems have to be absolutely reliable. maxon motor manufactures high-precision micro drives for medication delivery systems.

Fall River, MA — Motion Control Components Application – Patients that suffer from chronic pain, metabolic disorders, diseases of the central nervous system and tumor diseases require accurately dosed medication. Here implantable medication delivery systems are used. Through the localized medication delivery, the dosage can be reduced to the required minimum. These infusion systems thus improve the quality of life of the patients. For many patients, it is only the medication delivery system that allows them to have a life outside of the clinic. Repetitive invasive, painful operations can be avoided. The risk of medication dependency and undesired side effects are reduced to a minimum. All these factors can contribute to the disease no longer being the central focus of the patient’s life. For example, an active implant is implanted in the lower abdomen directly underneath the skin, where it delivers the medication dosage, programmed by the physician, to the body at the defined times of the day. The implantable unit has a wireless data interface to a patient interface by which the dosage can be adapted at any time. At regular intervals, the internal medication reservoir can be refilled by a specialist. The life span of the active implants measures many years and is limited only by the life of the battery. The core of the active implant is a piston pump manufactured by maxon medical, which specializes in medical technology and is a division of the maxon motor Group. However, the micro drives for implantable medication delivery systems are not comparable with customary maxon motors. In a customary motor, rotary motion is generated and yields torque and speed of rotation. The reciprocating piston pump generates a linear movement that results in liquid pumping. The individual parts of the pump have very narrow tolerances and allow the pump volume to be adjusted with a precision of less a microliter per piston stroke. As active implants are in direct contact with human tissue, biocompatible materials are an absolute requirement. Therefore, in most cases, titanium is used for the implants. Machining of titanium, especially safe and reliable laser welding, requires a very high level of expertise. Special testing and quality methods, such as inspecting the penetration depth, microhardness and density of the weld seams, are established procedures at maxon medical. The customer requirements on the product are thus fulfilled and the reliability and constant quality of the manufacturing processes are guaranteed. The entire assembly of the implantable micro drive takes place under cleanroom conditions. maxon medical – Specialist for medical drive solutions and active implants maxon medical specializes in the manufacturing of medical drive solutions for active implants. The division received ISO 13485 certification in December 2008. The quality management system and the project organization ensure safe, reliable and standard-compliant products and provide the customer with a sound basis for statutory approval of the final products. Professional project organization and a proven risk management system allow efficient implementation of customer projects. Strict maintenance of statutory requirements has top priority in the implementation of medical technology projects with risk class IIb + III. Production processes, production systems and testing systems always fall under GMP (Good Manufacturing Practice, Commission Directive 2003/94/EC), regardless of the classification of the product. maxon medical meets highest customer requirements – from selection of suitable suppliers to multi-tier quality control, from the individual parts to the final product. Manufacturing processes in the field of medical technology have very high documentation requirements during the entire value-added chain. All the way from the project idea to series production. In the end, a comprehensive and detailed documentation of all processes is required, including verification of process capability and traceability right back to the individual parts. This process control, matured to the last detail, characterizes maxon medical. It is an important and indispensable component of the entire production process and guarantees the high quality of the micro drives used for active implants of maxon medical. Contact maxon for more details info@maxonmotorusa.com Comprehensive documentation and software are included with every delivery, and are also available for you to download from our website at www.maxonmotor.com.

Motion Control – Pan-Tilt Stage

Van Nuys, CA – — Motion Control – High Resolution, Motorized, Pan-Tilt Stages have been added to the extensive line of OES (Optimal Engineering Systems, Inc.) motion control products. These motorized Pan-Tilt Stages are available in two sizes. The PT60-1 Pan-Tilt Stage is a combination of two 60 mm (2.362 in.) rotary stages and the PT100-1 is a combination of two 100 mm (3.937 in.) rotary stages, set at a 90O angle to each other. The rotary stages of each Pan-Tilt stage features a high repeatability of 0.005O (18 arc-sec), a positional accuracy of 0.005O (18 arc-sec), and a resolution of 0.001O = 3.6” (10 Micro-steps per Step Motor Driver in use). These Pan (horizontal table)-Tilt (vertical table) Stages are deal for: Scanning, testing, inspection, assembly, positioning, laser and micro machining, pointing optics and cameras, and other applications.

The pan and tilt axes on both stages have precision V-grove and crossed roller travel guides and are driven by a worm gear with just of 0.005O (18 arc-sec) of backlash. These compact, easily integrated motion control Pan-Tilt stages weigh just 2.0 kg (4.4 lbs) for the PT60-1 and 4.4 kg (9.75 lbs) for the PT100-1 and load capacities are 10 kg (22 lbs) and 20 kg (44 lbs) respectively). Each axis is driven by a standard bi-directional stepper motor with a knob for manual adjustments and each rotary axis has a vernier scale for setup. The knob on each motor can be replaced with an optional encoder for position verification. Travel speed of each axis is 12O per second with a stepper motor or for higher speeds and closed loop operation, servo motors are available. Electrical connections are made using 9 pin DB-9 connectors. The PT60-1 and the PT100-1 Pan-Tilt Stages can be ordered as complete plug-and-play systems with a multi-axis controller, joystick, trackball or keypad.

About OES “The Motion Control Company” – Optimal Engineering Systems, Inc. (OES) is a manufacturer of motion control products including: Stepper motor controllers and drivers, solenoid electronics, and positioning stages and slides. Applications include: Animation, automated assembly systems, automation, CNC machines, flight simulation, inspection systems, linear and rotary stages, machine tools, medical devices, motion control camera boom systems, optical comparators, CMMs, pan-tilt gimbals, PCB assembly & inspection, pick-and-place, positioning stages, robotics, scanners, security cameras, telescope drive mechanisms, time-lapse photography and winders. Some of the industries OES serves are: Aerospace, Astronomy, Chemical, Communications, Educational Institutes, University, Colleges, Government Agencies, National Labs, Manufacturing, Medical, Metrology, Military, Motion Control, Museum, News Agencies, Semiconductor and Test Equipment. Optimal Engineering Systems, Inc’s. competitive advantage is its state-of-the-art in-house manufacturing facility in North America enabling OES to supply clients with custom designed orders or high volume just-in-time deliveries globally.

For additional information, contact sales team at: OES, 6901 Woodley Ave.; Van Nuys, CA 91406; Telephone: 888-777-1826 or +1 818-222-9200, FAX +1 818-436-0446 or E-Mail: sales@oesincorp.com or visit the website at http://www.oesincorp.com

Motion Control – Digital Servo Amplifiers

Motion Control Components – Servo2Go.com announces the release of the DZRALTE Series of High Performance Digital Servo Drives from Advanced Motion Controls of Camarillo, CA, which are engineered to conquer the most demanding industrial applications!

The DZRALTE Series are motion control digital servo drives that control brushed & brushless servomotors in a compact form factor which make them ideal for embedded applications. These fully digital drives operate in torque, velocity, or position mode and employ Space Vector Modulation (SVM) which results in higher bus voltage utilization and reduced heat dissipation compared to traditional PWM drives. The command source can be generated internally or can be supplied externally. In addition to motor control, these drives feature dedicated and programmable digital and analog inputs and outputs to enhance interfacing with external controllers and devices.

The DZRALTE Series feature a RS-232 interface for drive configuration and setup as well as a RS-485 interface for drive networking. All drive and motor parameters are stored in non-volatile memory. Drive commissioning is accomplished using AMC’s powerful & user friendly free DriveWare software.

The combination of a DigiFlex® Performance™ DZRALTE servo drive with its DriveWare software establishes a new benchmark in versatility!

Motion Control Capabilities built into the DZRALTE servo drives include:

• Size Ranges: 10-175 VDC @ 6A to 30A continuous (60A peak) Output
• Full tuning control of all three servo loops: Position, Velocity and Torque!
• Real-time oscilloscope with up to 8 channels to ensure that tuning achieves the highest performance
• Status window with over 50 simultaneous channels for drive and system diagnostics
• I/O configuration configurable to latch/non-latch as well as active-high & active-low
• Universal servo motor compatibility by means of automatic commutation adjustment
• Dual Loop Feedback – Increases both stability and accuracy

Additional information on the DZRALTE Series Servo Amplifiers can be found at: https://www.servo2go.com/catalogsearch/result/?q=DZRALTE

These and other Motion Control Products are available through www.Servo2Go.com

For further information on this new product or others in our extensive product portfolio, call 1- 877-378-0240 or e-mail Warren Osak atwarren@servo2go.com or visit Servo2Go.com at: www.Servo2Go.com

See this and other Motion Control Components from Servo2Go featured on:
http://MotionShop.com
http://AllMotionBlogger.com
http://Automation-Blogger.com
http://MotionControlBlogger.com
http://motioncontrolBuyersGuide.com
http://MotionControlWeb.com
http://MotionShop.net

Motion Control Miniature Stepper Motor Stage

Forestville, CA, – — The motion control SMS12 Linear Stepper Motor stage is an ultra compact stage that provides up to 12 millimeters of linear motion. This stage offers near sub-micron resolution with the ability to accelerate a small load at 2G’s. A non-contact home sensor provides a reference position with repeatability of a couple microns.

It was specifically developed for optical applications requiring both high precision and modest-speed positioning over a short to medium stroke. The SMS12 is well suited for optical focusing and other micropositioning applications such as scanning interferometry, surface structure analysis, disk drive testing, autofocus systems, confocal microscopy, bio-technology, semiconductor test equipment.

Motion Control Specifications:

• Translation 43µm/step
• 0.67µm @ 64µstep/step
• Maximum Travel 12mm
• Maximum Acceleration 2G
• Maximum Velocity 250mm/sec
• Maximum Load Capacity 13kg
• Maximum Moment Load 1.8kg
• Positioning Accuracy ±2µm
• Bidirectional Repeatability ±1µm
• Homing Repeatability ±1µm
• Motor Amps/Phase 0.3
• Dimensions 39.1 x 39.1 x 31.75mm

The SMS12 can be ordered with an optional stepper motor controller that is nearly the same size a the SMS12 itself. Only raw power and a simple RS232/RS485 communications line is needed to completely control this high-resolution stage.  Equipment Solutions, Inc. (ESI) is a provider of engineering and manufacturing services. ESI specializes in the design and production of automation and instrumentation products including motion control components and sub systems. ESI’s products range from galvanometer amplifiers with an integrated arbitrary waveform generator, to high-resolution displacement sensors, voice coil and stepper motor stages, amplifiers and controllers. To view and/or down load the Data Sheet CLICK HERE For additional information contact Jeff Knirck at Equipment Solutions,Inc. Mailing Address – PO Box 159, Forestville, CA 95436; Shipping Address 6490 Front Street, Forestville, CA 95436; Tel: 408-245-7162, Fax: 408-245-7160, E-Mail: info@equipsolutions.com or visit the Website at http://www.equipsolutions.com

See this and other Motion Control Components from Equipment Solutions featured on:

http://MotionShop.com

http://AllMotionBlogger.com

http://Automation-Blogger.com

http://MotionControlBlogger.com

http://motioncontrolBuyersGuide.com

http://MotionControlWeb.com

http://MotionShop.net

http://Catalogs-MotionControl.com

http://MotionControlMarketing.com

http://Gotcha-Stick.com

Follow Equipment Solutions on Twitter

Follow Equipment Solutions on Facebook

Go to the Equipment Solutions Blog

Motion Control Brushless Motor

The new EC-i 52XL 200W Brushless Servo Motor from maxon is a powerhouse.  When space is limited but high torque and dynamics are required, the maxon EC-i 52XL motor is the ideal motor choice..

Vaughan, Ontario, Canada — Motion Control Components — With its extended length (80 ? 110mm), this motor with flux collector rotor provides outstanding torque performance compared to the existing EC-i 52 180W High Torque that is often needed, especially on the industrial automation front. Its extra power can be even more significant at relatively low speed which makes it a powerful fit to a variety of industrial applications including material handling & transport systems.

Motion Control Marketing – Adapting to the New Marketing Paradigm

A message for Motion Control Marketers

The role marketing is expanding!

As a marketer of technical products I make an effort to view the sales process as a consumer.  Fact – All consumers are not alike.  Speaking only for myself, although, I believe there are many like me, that want to do their own research, and ONLY talk to sales when they are ready to.

Depending on the consumer it may be early or late in the sales process.  Perhaps the sales funnel should reflect an overlap rather than have a line at which the process switches from marketing to sales.  That said, consumers need to be aware of a product, have their interest aroused, have cause to consider the product, and have an interest in purchasing the product.  Marketing today necessarily has a bigger role in the sales process than in years past.

Years ago (pre-internet) a potential customer saw a product release or an ad in a magazine, circled a number on a “Bingo Card” and got a sales call made on him.  Today the potential customer sees a product release or ad and starts to do his own research.  In addition to some reviews, he will find data sheets, application notes, videos, dedicated web pages, and blogs online (products of the marketing department) all of which will be carefully reviewed before a sales person is ever called.

Developing and implementing an effective Business-to-Business marketing program for technical products that:

Creates Awareness of …

Generates Interest in …

Causes Consideration of …

Raises the level of Intent to …

and

Aids in the Evaluation of …

Does not have to be expensive!

However, It does have to be well planned …       … and that plan has to be carried out.

For large companies the marketing program can include: Paid Advertising, Product Releases, an expensive interactive Website, a Blog, Data Sheets and Brochures.  All effective tools to create Awareness, Interest, Consideration, etc.

For smaller companies an effective reasonably priced, affordable marketing program can include: Product Releases, a Website, perhaps a Blog, and Data Sheets.

Product Releases are great for creating Awareness of, they also generate Interest in, and cause further Consideration of your products, each time the release is seen in a different print or online publication.

The Website does not have to have an expensively developed “WOW” factor as much as it has to have the information needed to determine if your product is right for the prospects application, or if you have the capability of supplying a custom product to meet or perhaps even exceed his or her needs.

A simple inexpensive blog, can also be an effective marketing tool.

Data Sheets …   … Create a straight forward format for an online data sheet that provides the technical data needed helps in the Evaluation that then can lead to the Sale!

 For over 30 years I have been marketing exclusively Motion Control products. First as a Marketing Manager and then as Marketing Consultant.  I have enjoyed working with several companies for over 20 years.  Email me at dwtechcom@gmail.com and see how inexpensive an effective marketing program can be.

Van Nuys, CA – — Motion Control – OES (Optimal-Engineering Systems, Inc.) has added a new, high precision open aperture stage to it’s expanding line of precision XY stages. The AU200-100×100 stage is a low profile stage measuring just 80 mm (3.150 in.) high with a compact footprint (including the motors) of 348 mm x 348 mm (13.701 in. x 13.701 in.) The linear travel of the X and Y axes is 100mm x 100mm (3.937 in. x 3.937 in.), and the resolution of each axis is 20 microns (non-micro-step) or 1 micron (20 micro-steps per step motor driver in use), repeatability is 2 microns, and the positional accuracy is 3 microns. The stages have preloaded V-groove and crossed roller bearings and ground 4 mm per-turn lead screws having just 2 microns of backlash, all contributing to the high precision and stiffness of the AU200-100×100 Stage. Designed for applications such as: Laser drilling, machining, medical, industrial, semiconductor handling, testing, scanning, alignment, assembly, and optical applications, this compact, low profile black anodized aluminum XY stage is easy to integrate into new or existing systems.

The XY stage’s table measures 300 mm x 300 mm (11.811 in x 11.811 in.) and the open aperture measures 188 mm x 188 mm (7.402 in. x 7.402 in.). A recessed mounting and precision pattern of drilled and threaded mounting holes facilitate the alignment of tooling or fixtures. Additionally, solid tooling plates are available for custom and interchangeable applications.

The standard two-phase (1.8 degree) stepper motors have knobs for manual adjustments of each axis of the stage, however, the knobs can be replaced with incremental encoders for position verification. As an option, servo motors and compatible motion controllers are also available from OES, or the AU200-100×100 Stage can be ordered as a complete plug-and-play motion control system.

About OES – Optimal Engineering Systems, Inc. (OES) is a manufacturer of motion control products including: Stepper motor controllers and drivers, solenoid electronics, and positioning stages and slides. Applications include: Animation, automated assembly systems, automation, CNC machines, flight simulation, inspection systems, linear and rotary stages, machine tools, medical devices, motion control camera boom systems, optical comparators, CMMs, pan-tilt gimbals, PCB assembly & inspection, pick-and-place, positioning stages, robotics, scanners, security cameras, telescope drive mechanisms, time-lapse photography and winders.

Some of the industries OES serves are: Aerospace, Astronomy, Chemical, Communications, Educational Institutes, University, Colleges, Government Agencies, National Labs, Manufacturing, Medical, Metrology, Military, Motion Control, Museum, News Agencies, Semiconductor and Test Equipment. Optimal Engineering Systems, Inc’s. competitive advantage is its state-of-the-art in-house manufacturing facility in North America enabling OES to supply clients with custom designed orders or high volume just-in-time deliveries globally.

For additional information, contact sales team at: OES, 6901 Woodley Ave.; Van Nuys, CA 91406; Telephone: 888-777-1826 or +1 818-222-9200, FAX +1 818-436-0446 or E-Mail: sales@oesincorp.com or visit the website at http://www.oesincorp.com

EXOR has taken the highly successful harsh environment eTOP500 series and updated it with the recently released eX700 series.

Vaughan, Ontario, Canada — Motion Control Components — This natural progression allows you to combine a high-performance sunlight readable display with state of the art connectivity such as OPC UA.

eX700G Series combine high-performance sunlight-readable display with state-of-the-art connectivity features and top performance in a great design maintaining as a design commitment the fact that the product is likely to be used in environments where the safety of operators is at risk

EXOR has designed the product range as Industrial IoT edge devices combining a powerful controller with networking capability and outstanding communication options including client/server OPC UA. They are the ideal choice for all demanding IIoT edge applications in extreme environments such as marine and process industries.

The glass projected capacitive touchscreen and the brilliant 7” widescreen display with a resolution of 800×480 are bonded to guarantee the highest optical performance and resistance in such environments.

As with all eX700 Series HMI products have been designed to run the JMobile software.

• JMobile runtime included. Requires JMobile V2.8 or higher
• Supports Corvina Cloud secure connectivity with full network separation
• OPC UA Server and Client
• Optional CODESYS V3 runtime with choice of EtherCAT, PROFINET, Ethernet/IP and POWERLINK

Information on the eX707G HMI from Exor can be viewed at:

https://www.electromate.com/assets/catalog-library/pdfs/exor-electronics/Exor_eX707G_Specsheet.pdf

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Google+: https://plus.google.com/104057418684128701566

Blog: https://electromate.wordpress.com/

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com

The AB25A100 PWM servo drive from Advanced Motion Controls is designed to drive brushless and brushed DC motors at a high switching frequency.

Greenville, DE —-Motion Control Components – The drive is fully protected against overvoltage, under-voltage, over-current, over-heating and short-circuits across motor, ground and power leads. Furthermore, the drive can interface with digital controllers or be used stand-alone, and requires only a single unregulated DC power supply. Loop gain, current limit, input gain and offset can be adjusted using 14-turn potentiometers. The offset adjusting potentiometer can also be used as an on-board input signal for testing purposes. This drive can use quadrature encoder inputs for velocity control.

Features include:

• 20-80 VDC Input, 15 A Cont. (25 Peak) Output
• Built-in hardware protection – Over Current, Over Voltage, Under Voltage, Over Temperature, Short Circuit
• DIP Switches and Potentiometers for loop tuning, current limit adjustments and drive configuration
• Standard models support both brushless and brushed motor types
• Velocity feedback via incremental encoder, Hall Sensors, or tachometer
• Optical isolation between high and low power signals standard on certain models
• Current, Velocity, and Fault Monitor analog output signals
• Status LEDs for power and drive status
• Four quadrant regenerative operation

CLICK HERE for more information on the AB25A100 Servo Drive from Advanced Motion Controls.

These and other Motion Control Products are available through www.Servo2Go.com

For further information on this new product or others in our extensive product portfolio, call 1- 877-378-0240 or e-mail Warren Osak atwarren@servo2go.com or visit Servo2Go.com at: www.Servo2Go.com

Motion Control Speed Reducer

North Babylon, NY – Motion Control Components – Rolling Motion Industries (RMI) is changing the world of mechanical power transmission! New Two Way MAR-17-2-3:1 and the MAR-23-2-3:1 Speed Reducers using Traction Drive Technology leveraged engineering fluids and precision manufacturing with a simple design that features exceptional reliability and up 98% efficiency! The MAR17-2-3:1 Speed Reducer is designed for input speeds up to 3600 rpm with 10 to 20 in/lbs of torque, and the MAR-23-2-3:1 Speed Reducer is also rated for speeds to 3600 rpm but with an input of 20 to 30 in/lbs of torque.

Motion Control Technology –

The propriety engineered traction fluid with a coefficient of friction of just 0.1 to 0.12 transmits torque between the four driving and driven elements. The traction fluid continuously changes from liquid-to-solid-to-liquid in the microscopic spaces between the driving and driven elements. Even though there is no metal-to-metal contact there is no slippage! These compact speed reducers are quiet, generating up to 72% less heat even after weeks of continuous operation, and offer thousands of hours of trouble free operation, as the traction fluid cools and lubricates the traction drive speed reducers. Having low vibration, and no torque losses from 10 to 3000 rpm, these 3:1 2 way speed reducers let motors operate at peak efficiency while having a damping effect on a motor’s torque ripple. The speed reducers are available with an optional overriding clutch to protect the components as they can not be back driven. Incorporating standard NEMA mounting dimensions, they can be easily integrated into new and existing applications. Creating 38% lower dB at 3000 rpm than conventional gearboxes these people friendly speed reducers are ideal for use in medical equipment such as mobile hospital equipment and dialysis machines as well as pumps, blowers, fans, turbo and super chargers, conveyers, HVAC systems, and other power transmission and motion applications.

About Rolling Motion Industries (RMI)- About Rolling Motion Industries (RMI): In 1993 John Pawloski and his brother Ray took over the family business, Jewelers Machinist Co. They realized they needed to switch from outdated conventional thread grinders to CNC thread grinders. As a result, Jewelers Machinist Co is recognized as the source of some of the most complex thread grinding in the industry. The concept for the RMI traction drive came from John in 2007. Working in that high precision industry aided John in the development of the RMI Traction Drive. In the years that followed, the design of the individual components and formula of the engineered traction fluid were finalized, testing was completed, a patent granted, and production begun. The RMI Traction Drive is one of the most efficient ways to transmit power from one point to another. Utilizing rolling motion, RMI is able to transfer power at various ratios with minimal energy loss. Tested against V-belt, direct drive, chain, and gearbox setups, RMI Traction Drives offer energy saving benefits through true efficiency rating percentages up to 98%. The high efficiency of the traction drive allows electric motors to run at their peak efficiency ranges. There are many applications where it can be used from automotive to industrial to medical. The RMI traction drive can be used in the electric vehicle market and precision applications. Offering benefits such as low backlash and no back driving, it set a new standard for “high efficiency”. For additional information contact our sales team at Rolling Motion Industries, 400 Columbus Ave, North Babylon, NY 11703 Tel 860-846-0530, E-Mail info@RMIDrive.com or visit the website at http://www.RMIDrive.com

Motion Control Linear/Rotary Actuator

Vaughan, Ontario, Canada –Motion Control – The LCR16 from SMAC Moving Coil Actuators provides precision Z-theta motion within one small actuator, which is ideal for a pick, orient and place applications.  A wide variety of LCR16 linear rotary actuators are available with either direct drive or gearbox equipped rotary units.>

The vacuum-built-in shaft through the rotary motor is available for some models to prevent dust build-up in the unit.  These z-theta actuators can easily be programmed to control force/torque, position and velocity in all axes at the same time with feedback capability.  SMAC’s unique, patented “Soft-Land” function enables the unit to gently land on a delicate component with a controlled force to avoid damage of both the component and the actuator.

The actuator is constructed with a direct drive brushless servo motor.  It’s designed with linear guide built-in lubrication to offer long life cycle.  Moreover, it provides absolute control over: force/torque, position, acceleration and velocity.

Features include:

• Direct drive brushless servo motor
• Combined linear and rotary motions in a single unit
• Fully programmable in force/torque, position and velocity
• SMAC’s Patented ‘Soft-Land’ Technology
• Self-lubricated linear guide
• Low shaft run-out, 30µm (Lower run-out optional)
• Vacuum through shaft prevents dust accumulation
• MTBF 100 million life cycle

• JMobile runtime included. Requires JMobile V2.8 or higher
• Supports Corvina Cloud secure connectivity with full network separation
• OPC UA Server and Client
• Optional CODESYS V3 runtime with choice of EtherCAT, PROFINET, Ethernet/IP and POWERLINK

Information on the LCR16 Series Linear Rotary Actuator from SMAC can be viewed at:
https://www.electromate.com/assets/catalog-library/pdfs/SMAC/SMAC_LCR16_Linear_Rotary_Actuator_Brochure.pdf

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.

More on Electromate can be found at

Website: http://www.electromate.com

LinkedIn: https://www.linkedin.com/company-beta/209277/

Twitter: https://twitter.com/Electromate

Facebook: https://www.facebook.com/electromateindustrial/

Google+: https://plus.google.com/104057418684128701566

Blog: https://electromate.wordpress.com/

For more information on the “Best Place to Work”CLICK HERE!

To view Electromate’s new corporate video CLICK HERE

For further information on this new product or others in our extensive product portfolio, call 1-877-SERVO99 (737-8699) or e-mail Warren Osak at sales@electromate.com or visit Electromate at: www.electromate.com

For other Motion Control Components, Applications, and Technology from Electromate visit: http://MotionShop.com
